GENERAL SPECIFICATIONS
|
Nominal Diameter |
10 |
Inch |
|
|
Rated Impedance |
8 |
Ω |
|
|
Power Handling Capacity |
200 |
Watts |
|
|
Sensitivity 1W 1M |
94.8 |
dB |
|
|
Effective Piston Diameter |
210 |
mm |
|
|
Voice Coil Diameter |
51.1 |
mm |
2 Inch |
THIELE-SMALL PARAMENTERS
|
Resonance Frequency |
Fs |
65 |
Hz |
|
DC Resistance |
Re |
5.8 |
Ω |
|
Mechanical Q Factor |
Qms |
2.365 |
|
|
Electrical Q Factor |
Qes |
0.453 |
|
|
Total Q Factor |
Qts |
0.380 |
|
|
BL Factor |
BL |
12.879 |
TM |
|
Effective Moving Mass |
Mms |
31.670 |
gr |
|
Equivalent Cas Air Load |
Vas |
32.147 |
liters |
|
Effective Piston Area |
Sd |
0.035 |
㎡ |
|
Half-Space Efficiency |
Eff |
1.894 |
% |
|
Top Palte Thickness |
Hag |
6 |
mm |
|
Voice Coil Height |
Hvc |
14 |
mm |
|
Voice Coil Over-Hung |
Xmax |
5.0 |
mm |
PHYSICAL INFORMATION
|
Magnet |
140×60×20 Ferrite |
|
Voice Coil Winding Material |
Copper |
|
Cone Material |
Pulp Paper |
|
Overall Diameter |
256mm |
|
Baffle Cutout Diameter |
232mm |
|
Mounting Holes |
8 holes ∅ 248mm |
|
Total Depth |
117mm |
